Compact levels switch

      SOR cuts no corners in manufacturing its compact levels switches. Our best-selling 1500 Series level instruments are machined from stainless steel and stands up to the harshest of process environments. Designed to meet our customers’ demands for highly efficient level switch products that require less space.

      Stands up to harsh conditions

      • All stainless steel construction and switching mechanism
      • Magnetic coupling action keeps the switch isolated
      • Low price
      • All ASTM materials

      Safe and effective

      • Safety certified to SIL IEC61508
      • Standard rating of 1500 psi @ -40 to 400OF (103 bar @ -40 to 240OC)
      • Low power, pneumatic and manual check options

      Product support

      • Feel free to contact our engineers with questions and help in choosing the right switch for your application

      Reduces your inventory

      • Side mounted switches may be oriented for high or low level action

      1510 Side Mounted Level Switch

      1510 Side Mounted compact Level Switch

      Models: 1510
      Ranges: vac to 5000 psi, vac to 345 bar; -40° to 400°F, -40° to 204°C
      Certifications: Unit: ATEX, CSA (US and Canada), GOST, INMETRO, RTN, SIL
      Warranty: 5 Years

      The 1510 is a side mounted float compact level switch that features a Manual Check and a Low Power option. Actuation/deactuation can be reversed by rotating the unit 180 degrees.This is a low-cost, rugged, float level switch suitable for harsh and rugged applications in oil and gas, refining and process industries.

      The 1510 is available with explosion proof/flameproof and intrinsically safe options along with other worldwide agency approvals.

      • Maximum process pressure up to 5000 psi (345 bar)
      • Process temperature range -40 to 204°C
      • NPT or Flange connections
      • Hermetically sealed switch
      • Manual check and low power options

      Datasheet

      Ready to find out more?

      Drop us a line today for a free quote!

      1530 Side Mounted Pneumatic Level Switch

      1530 Side Mounted Pneumatic compact Level Switch

      Models: 1530
      Ranges: vac to 5000 psi, vac to 345 bar; -40° to 400°F, -40° to 204°C
      Certifications: Unit: RTN
      Warranty: 5 Years

      The 1530 is a side mounted float-operated pneumatic compact level switch. The float moves a magnet that actuates or de-actuates a pneumatic 3-way valve. It is suitable for plant and OEM applications where pneumatic valve operation is required to signal presence or absence of liquid at a discreet level.

      • Designed to ANSI B31.3 specifications
      • 316 stainless steel (1500 psi), Monel (900 psi) or polypropylene (5000 psi) float material
      • NPT or flange connections
      • Hermetically sealed switch

      Datasheet

      Ready to find out more?

      Drop us a line today for a free quote!

      1540 Side Mounted – Non-Bleed Pneumatic Level Switch

      1540 Side Mounted Pneumatic compact Level Switch

      compact Models: 1540
      Ranges: vac to 1500 psi, vac to 100 bar; -40° to 400°F, -40° to 204°C Maximum process pressure 60 SCFH (1.7 CMH)
      Certifications: Unit: RTN
      Warranty: 5 Years

      The 1540 is a side mounted, float-operated, non-bleed pneumatic level switch suitable for plant and OEM applications where open or closed contacts are required to signal presence or absence of liquid at a discrete level. The float arm moves a magnet which in turn moves a shuttle that either blocks or allows pilot pressure to pass and operate ancillary equipment. A manual check option allows you to verify switch integrity without removing the unit from the vessel.

      • Maximum process pressure – 1500 psi (103 bar)
      • Suitable for air or any dry or filtered gas
      • Manual check option

      Datasheet

      Ready to find out more?

      Drop us a line today for a free quote!

      1550 Top Mounted Level Switch

      1550 Top Mounted compact Level Switch

      Models: 1550
      Ranges: vac to 473 psi, vac to 32.6 bar; -40° - 400°F, -40° - 204°C
      Certifications: Unit: ATEX, CSA (US and Canada), GOST, INMETRO, RTN, SIL
      Warranty: 3 Years

      The 1550 is a float-operated top mount compact level switch. The float moves a magnet that actuates or deactuates a hermetically sealed reed switch.  A Low Power option is available. Available with flameproof/explosion proof or intrinsically safe certifications. The 1550 also carries other worldwide agency approvals.

      • Hermetically sealed reed with 18” 20 AWG wire leads
      • Maximum process pressure up to 473 psi (32.6 bar)
      • Maximum insertion depth 48” (122 cm)
      • Low power option

      Datasheet

      Ready to find out more?

      Drop us a line today for a free quote!

      1710 Compact Level Switch

      1710 Compact compact Level Switch

      Models: 1710
      Ranges: vac to 1799 psi (124 bar) -40° to 700°F (371°C)
      Certifications: Unit: ATEX, CSA (US and Canada), GOST, IEC, KOSHA, SIL
      Warranty: 5 Years

      The SOR 1710 is a direct mounted, horizontal, float-operated level switch suitable for plant and OEM applications where open or closed contacts are required to signal presence or absence of liquid at a discrete level. While the 1710 shares a lot in common with its cousin the 2210, the 1710 differs in a couple key features.

      First, the 1710 is designed to handle hazardous environments. Worldwide Flameproof/Explosion proof listings are standard on each and every 1710. No additional cost, no additional accessory codes to remember.

      Second, the 1710 can be ordered as a direct mounted device or with an optional chamber. This gives OEMs and plants the flexibility to mount the 1710 directly in the side of the vessel whenever possible, saving cost. The 1710 can also be supplied with a chamber providing most of the functionality of the 2210 but with hazardous location approvals.

      SOR is once again pushing the boundaries of traditional technology providing more value than ever before.

      • Field proven design
      • Compact size
      • Direct mount or chambered versions available
      • Rated for process temperatures up to 800°F (427°C) and pressures up to 1500 psi (103 bar).
      • CSA (US and Canada) Explosion proof and ATEX/IEC Flameproof approvals on all units

      Datasheet

      Ready to find out more?

      Drop us a line today for a free quote!

      Certifying Agencies

      ATEX (certified by Baseefa, DEMKO, or KEMA)

      CE

      CSA

      FM

      GOST

      IECEx (certified by Baseefa or Standards Australia)

      INMETRO

      PESO (CCOE – India)

      TIIS

      KOSHA

      Rostechnadzor (RTN)

      SIL, TestSafe (SAA – Australia)

      SASO

      UL

      Available Listings

      Ordinary Locations and Hazardous Locations
      SIL Level Switch Certificate
      SIL Pressure Switch Certificate

      Available Hazardous Locations Protection Methods

      Explosion Proof/Flameproof (d)
      Intrinsic Safety (ia)
      Encapsulation (m)
      Special Protection (s)
      Combustible Dust (tD)
      Energy Limited (nL)

      Division 1, Division 2
      Class I, Class II, Class III
      Groups A-G
